Single Phase Off-grid Inverter NKI-PV6000-48

NUUKO Single Phase Off-grid Inverter NKI-PV6000-48

Built-in 80A Solar Charger

Wide MPPT Range 120-500V

Workable with Generator

Dual AC Output

9 Inverters in Parallel

Support Lithium/Lead-acid Battery

Lithium Battery Activation

Detachable Dust Cover

Feed-into Grid

WiFi Monitoring(optional)

  • Brand:

    NUUKO
  • Item NO.:

    NKI-PV6000-48
  • Mechanical Specifications


Specifications

Model
NKI-PV6000-48
AC Input

Rated Input Voltage (VAC)
208 / 220 / 230 / 240; L + N + PE
Voltage Range (VAC)
90~280±3 (normal mode); 170~280±3 (UPS mode)
Frequency (Hz)
50 / 60 (Auto Adaptive)
AC Output

Rated Capacity (kW)
5
Surge Power (kVA)
10
Voltage (VAC)
208 / 220 / 230 / 240
Power Factor (PF)
1
Frequency
50/60Hz±0.1%
Switch Time (ms)
10 (normal mode) / 10 (UPS mode)
Wave Form
Pure Sine Wave
Overload Capacity (Batte Mode)

60s@102%~110% load; 10s@110%~130% load;

3s@130%~150% load; 0.2s@>150% load

Max. Effciency (Batte Mode)
93%@48VDC
Parallel Quantity
9
Charger (PV / AC)

Solar Charger Type
MPPT
Max PV input current / power
18A / 6000W
MPPT Range@Operating Voltage (VDC)
120~450
Max PV Open Circuit Voltage (VDC)
500
Max PV Charge Current (A)
80
Max AC Charge Current (A)
80
Max. Charge Current (PV + AC) (A)
80
Battery
Normal Voltage (VDC)
48
Floating Charge Voltage (VDC)
54
Overcharge Protection (VDC)
61
Batte Type
Lithium and Lead-acid
Interface

HMI
LCD
Interface
RS485 / RS232 / USB / Dry Contact
Monitoring
WiFi (Optional)
General Data

Ingress Protection
IP21
Operating Temperature
-10℃~50℃
Relative Humidity
5%~95% (Non-condensing)
Storage Temperature
-15℃~60℃
Net Weight (kg)
9.5
Dimensions (W*H*D)
510*306*115mm (without bracket)
Max. Operating Altitude
4000m (Derating above 1000m)


Advantages of NUUKO Single Phase Off-grid Inverter NKI-PV6000-48


Built-in 80A Solar Charger:
Ensures efficient solar energy utilization, reducing dependency on external power sources.


Wide MPPT Range (120-500V):
Enhances compatibility with various solar panel configurations, maximizing energy harvest under different sunlight conditions.


Workable with Generator:
Allows seamless integration with generators, ensuring a reliable backup power solution during low solar availability.


Dual AC Output:
Supports multiple loads simultaneously, providing flexibility in power distribution for diverse applications.


9 Inverters in Parallel:

Enables scalability to meet higher energy demands, suitable for both residential and commercial systems.


Support for Lithium/Lead-acid Battery:

Offers compatibility with various battery types, giving users the flexibility to choose based on their needs and budget.


Lithium Battery Activation:

Simplifies the setup process and ensures the optimal performance of lithium batteries.


Detachable Dust Cover:

Enhances product durability by protecting internal components from dust, ensuring longer operational life.


Feed-into Grid Function:

Allows excess energy to be fed back into the grid, contributing to energy efficiency and potential cost savings.


WiFi Monitoring (Optional):

Provides remote system monitoring and management, offering convenience and real-time control over energy performance.


Application scenarios of NUUKO Single Phase Off-grid Inverter NKI-PV6000-48


Residential Use:

Ideal for homes in off-grid areas, providing a stable and efficient power supply with renewable energy integration.
Commercial Applications: Suitable for small businesses or workshops needing a reliable off-grid power source with scalable capacity.


Backup Power Systems:

Acts as an efficient backup solution during grid outages or in areas with unreliable electricity supply.


Solar Farms:

Can be used in solar energy projects to enhance system efficiency and manage energy distribution.


Rural Electrification:

Perfect for remote locations where grid access is unavailable, enabling sustainable development.


Hybrid Systems:

Combines solar energy with generators or grid inputs for robust and uninterrupted power solutions.


This inverter is a versatile, durable, and efficient choice for diverse energy needs, ensuring sustainability and cost-effectiveness.
